Bubble Filtration Water Device for Large-Scale Sewage Filtration Construction Site

Condition : New

Applicable Industries : Hotels, Manufacturing Plant, Food & Beverage Factory, Restaurant, Food Shop, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company

Showroom Location : Indonesia, Pakistan, India, Chile, Bangladesh

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Hot Product 2019

Warranty of core components : 1 Year

Core Components : Gearbox, Motor, PLC

Place of Origin : Sichuan, China

Brand Name : TOP

Material : container, Stainless Steel

Weight : 1000kg

Size : 1000mm*1500mm*1200mm

Power : 2..02

Warranty : 1 Year, 1 year

Productivity : 95%

Weight (KG) : 2500 kg

Supporting equipment : Auto Dosing Equipment, Sludge dewatering machine, Sludge pump

Type : Water Filter Parts

Color : Grey

Function : Solid-liquid Separation

Certification : ISO9001:2008

Capacity : 1-200m3/h/set

Application : Textile and dyeing, paper mill, municipal, dairy plant, food, etc.

Voltage : 380V /Customized

Packaging Details : Standard package
Cheap Factory Price DAF Dissolved Air Flotation System

Port : Shanghai/Shenzhen

Supply Ability : 30 Set/Sets per Month Cheap Factory Price DAF Dissolved Air Flotation System

Price : $8,999.00/sets 1-4 sets

MOQ : 1pc

Contact Now

TPNF Micro Nano Dissolved Air Flotation Machine

Product Description

TPNF Micro Nano Dissolved Air Flotation Machine consists of air floatation tank, micro nano system, scraping device (combined, driving and chain plate according to user needs) and electric control cabinet. In the water supply and drainage treatment process, solid and liquid separation technology and machine are one of the key projects. Air flotation is one of the most effective methods for the removal of tiny suspended particles with a specific gravity close to that of water.

Bubble Filtration Water Device for Large-Scale Sewage Filtration Construction Site

Dissolved Air Flotation Machine Working principle

Bubble Filtration Water Device for Large-Scale Sewage Filtration Construction Site

Dissolved Air Flotation Machine Advantages

  • SS remove rate can reach more than 95%

  • The clean water treated by TPNF is then filtered through a special structure filter element to achieve ultra-clear water

  • Compact design, easy maintenance, and short maintenance time.

  • The operating cost is low and small chemical use amount

Dissolved Air Flotation Machine Process control

Bubble Filtration Water Device for Large-Scale Sewage Filtration Construction Site

Models and Tips

Model

Capacity

(m3/h)

Volume of dissolved air water

(m3/h)

Main Power

(kw)

Aerated motor

(kw)

Scraper

(kw)

Total Power

(kw)

TPNF-1

0.5-1

0.3-0.5

0.55

0.55

0.18

1.28

TPNF-2

1-2

0.5-0.8

0.55

0.55

0.18

1.28

TPNF-3

2-3

1-1.5

1.1

0.55

0.37

2.02

TPNF-5

3-5

1.5-2

1.1

0.55

0.37

2.02

TPNF-10

5-10

3-4

1.5/5.5

0.75

0.37

2.62/6.62

TPNF-15

10-15

4-5

2.2/5.5

0.75

0.37

3.32/6.62

TPNF-20

15-20

5-7

2.2/5.5

0.75

0.37

3.32/6.62

TPNF-30

20-30

8-12

5.5

0.75

0.37

6.62

TPNF-40

30-40

10-15

5.5

0.75

0.37

6.62

TPNF-50

40-50

15-18

7.5

1.5

0.37

9.37

TPNF-60

50-60

18-20

7.5

1.5

0.37

9.37

TPNF-70

60-70

20-25

11

2.2

0.55

13.75

TPNF-80

70-80

25-30

11

2.2

0.55

13.75

TPNF-100

80-100

35-40

15

2.2

0.55

17.75

TPNF-150

120-150

40-50

15

2.2

0.55

17.75

TPNF-200

180-200

70-80

22

4

1.1

27.10

Customer Visitations

With our consistent effort,Our machinery is supplied to more than 30 countries including the Russia,Pakistan,India,Argentina,Indonesia,Romania,Canada,Turkey,Vietnam and other countries. Also participate in the exhibitions of urban sewage treatment, wastewater treatment, textile, leather, chemical and other industries.

Bubble Filtration Water Device for Large-Scale Sewage Filtration Construction Site

Related products

Bubble Filtration Water Device for Large-Scale Sewage Filtration Construction Site

About us

Top machinery, founded in 2002, specialized manufacture wastewater treatment equipment and sludge dewatering machine, like screw type sludge dewatering machine, decanter centrifuge, brushing/scraping self-cleaning filter, automatic back-flushing filter, Bernoulli filter, electrocoagulation, inward/outward water micro filter, bar screen, etc. With our consistent effort, high quality, competitive price and good after-service, our machines are supplied to more than 30 countries with very good feedback.
